turbodiesel

Ford 8.8 swap....

Post by turbodiesel » Mon Apr 10, 2006 11:30 pm

If you rewelded the lower mounts.... The axles are very similar in width. What about the upper control arms? I wonder if the differnce in the "ears" is too substantial. I plan on running spherical bushings on both ends.

I just thouht about it... 8.8 is a dime a dozen (so are 7.5 housings) I wonder if you could combine the two?

8.5s are getting $$$ and hard too find so are 12 bolts.

Perryk
Dragway Regular
Posts: 1055
Joined: Wed Jun 22, 2005 10:39 am
Location: montana

good idea

Post by Perryk » Tue Apr 11, 2006 1:25 am

I have read that some V8 S10s are using them. But they need a huge backspacing for wheels.

Why wouldnt it work well with a custom pair of control arms?

And those older foxbodies are running 9s with the 8.8.

Perry

User avatar
GreenDragginBu
Pro Moderator
Posts: 6293
Joined: Thu Jul 10, 2003 10:12 pm
Location: N.E. Ohio

Post by GreenDragginBu » Tue Apr 11, 2006 2:54 am

i actually have a old carcraft...i believe that has a blue malibu with a 8.8 under it. i check tomorrow if i can find it.
1979 Green malibu 57K original, 355/TH350/9"
---------------------------------------------------
"Its not as fast as money can buy,
its as fast as my pocket can afford"

User avatar
Wagonized
Dragway Regular
Posts: 1066
Joined: Sun May 25, 2003 6:51 pm
Location: abbotsford bc canada

Post by Wagonized » Tue Apr 11, 2006 6:10 am

a lot of s10 guys do this swap because the shock mounts are the same, control arms in the same place, and the leafs obviously work with it. Aswell as the same brakelines. Just needs a $20 driveshaft adapter

i think its about 3 inches wider total (although it might be per side) so most guys get corvette or camaro wheels to fit.

also the explorer comes stock with 3:23, 3:55 or 3:73 gearing, very commonly a decent posi, always 31 spline axles and sometimes disc rear brakes.

All in all its a great upgrade for an s10 but in a gbody its basically the same amount of fabbing as any other non fitting rear.
---- UNDER CONSTRUCTION ----
---- 1981 1000 HP GALLARDO ORANGE TURBO LS STREET WAGON ----

turbodiesel

Post by turbodiesel » Tue Apr 11, 2006 3:43 pm

Whats is the actual measurment backing plate to backing plate on a 7.5? Anyone know off hand?

I may just go measure my Cutlass...


Reason I am so interested is that I have an 8.8 from a fox that was removed years ago it still looks brand new. Its 5-lug conversion with 4.10's already. Just somthing I have laying around.

May have to add a 5 on 4.5 wheels on the back but oh well...

turbodiesel

Post by turbodiesel » Tue Apr 11, 2006 3:55 pm

I just measured both of them...

Ford 8.8 = 54 1/8"

Chev 7.5 = 54 1/2"

pretty dang close

84cutlass357

and...

Post by 84cutlass357 » Tue Apr 11, 2006 4:22 pm

what can be cool is that most weld draglites are 5x4.75 AND 5x4.5 so maybe you can muster up a set and just use diff holes and no one will be the wiser!
rob

ps---8.8 fan here

User avatar
Longroof79
MalibuRacing Junkie
Posts: 8920
Joined: Mon May 10, 2004 10:12 am
Location: Gainesville, Fla.

Post by Longroof79 » Tue Apr 11, 2006 4:40 pm

I think the 8.8 is a great rear if you can adapt it to our cars. They're a heck of alot more plentiful than GN, 442, T-Type 8.5 rears.
Jack ;)
Jack
'79 Malibu wagon, mild 355 sbc, TH350, 8.5 GN rear, 3.08 hwy gears.
Future updates include new A/C, built 200-4R trans, 3.42 gears, tinted glass, etc.
Blazer front brake upgrade
==================================

Stangboy
Dragway Regular
Posts: 833
Joined: Tue Jan 27, 2004 10:59 pm
Location: Ky

Post by Stangboy » Tue Apr 11, 2006 4:59 pm

This is interesting....
2002 C5 ECS glide no motor yet.
2000 SS Camaro
1980 Malibu
1970 Nova


sleek79

Post by sleek79 » Tue Apr 11, 2006 5:13 pm

i think i am going to look for one. now any explorer rear? are they posi? that be sweet

User avatar
Wagonized
Dragway Regular
Posts: 1066
Joined: Sun May 25, 2003 6:51 pm
Location: abbotsford bc canada

Post by Wagonized » Tue Apr 11, 2006 6:12 pm

91-94 explorer rear.

not all are posi
---- UNDER CONSTRUCTION ----
---- 1981 1000 HP GALLARDO ORANGE TURBO LS STREET WAGON ----

1BAD81BU
Pro Stocker
Posts: 2235
Joined: Wed Aug 06, 2003 2:25 pm
Location: Whiteland, IN.

Post by 1BAD81BU » Tue Apr 11, 2006 7:26 pm

BUMP, for a good topic. I might be interested in this too. I need another rear to replace the 7.5 posi I already have. Nick
1981 Malibu-357SBC-New Best! 12.34@108.8 Now Sold!
1983 Malibu Wagon-357SBC-No ET's yet, look for it in 2012!
GO COLTS!!!!

turbodiesel

Post by turbodiesel » Tue Apr 11, 2006 8:59 pm

For all the guys with G-bodies you have to use a mustang or thunderbird rear because of the cast "ears" for the upper controll arms. The sn-95 rears are 1 1/2" wider 94-98. And also new-edge is wider 99-04. The best would be 8.8 out of a 79-93 mustang. I find them for $100 a pop alot around here.

*** (I may be wrong about the explorer rears)*****
-Are they leaf spring or factory 4-link? Im not sure.


I guess Im gonna try this rear, Hopefully I will pick up my next project car saturday!

turbodiesel

Re: and...

Post by turbodiesel » Tue Apr 11, 2006 9:11 pm

84cutlass357 wrote:what can be cool is that most weld draglites are 5x4.75 AND 5x4.5 so maybe you can muster up a set and just use diff holes and no one will be the wiser!
rob

ps---8.8 fan here
Yeah, It would be hard to notice that for sure (especially with 5/8" studs ;))

I have always been an 8.8 fan. I have seen several cars in the mid-8's with an 8.8 rear. I had one mustang that was a DR car with 33 spline axles and a spool 5/8" studs. I dont think anything would break it that is still "stock suspension" (35 spline is available have to install big ford ends)

The best part is... it is stronger than a 8.5 10 bolt (ring gear issue) may be stronger than a 12 bolt (definatly on par) and takes about 10hp less to turn than a ford 9" due to the pinion location :)


What has to be modified...

-Have to weld on spring perches
-May have to modify the LCA mounts
-Custom upper control arms (mustangs wider apart)

Nothing really different than a 12-bolt except the LCA mounts, and surely the cost of that would be offset buy the relativly cheap price for parts for an 8.8......

User avatar
Longroof79
MalibuRacing Junkie
Posts: 8920
Joined: Mon May 10, 2004 10:12 am
Location: Gainesville, Fla.

Post by Longroof79 » Wed Apr 12, 2006 6:56 am

Turbo Diesel,
Thanks for the good information. Perhaps some one could do a tech section/ article on swapping in a Ford 8.8 rear into a Malibu/ G-body...*hint, hint*
Jack ;)
Last edited by Longroof79 on Wed Apr 12, 2006 7:18 pm, edited 1 time in total.
Jack
'79 Malibu wagon, mild 355 sbc, TH350, 8.5 GN rear, 3.08 hwy gears.
Future updates include new A/C, built 200-4R trans, 3.42 gears, tinted glass, etc.
Blazer front brake upgrade
==================================
