Just an FYI.

I bought a pair of Speedway Motors front upper a-arms. These are chromoly tubing with aluminum cross shafts. Part number for both right and left side a-arms are 91034393-R.


Speedway motors a-arms have no travel stops built in like the stock a-arms, but you loose about 4.5 lbs per side (roughly 9 lbs total) with these a-arms. The weight comparison included both a-arms having ball joints already installed.

8.7 lb - Stock A-arm weight
4.2 lb - Speedway Motors A-arm part# 91034393-R weight

These cross shafts have zerk fitting to lubricate the solid bushings.

There is also a little more clearance above cross shaft versus the stock control arms which may help in header or down pipe clearance.

Here is a link with another person using them on an S10.
